Cutaway of air bag module showing internal componets. Also known as the EDR, event data recorder, and black box.

Sample GM air bag module black box / SDM / EDR / event data
recorder / accident crash data using the Bosch / Vetronix
crash data retrieval tool (CDR).


Please feel free to contact us if you require further

information or need a GM air bag SDM downloaded.


Most early GM air bag modules will contain 5-15 pages of crash data. Many 2006
and newer air bag modules can contain 30-50 pages of crash data information.
A recent download from a 2010 Chevrolet Camaro
produced 71 pages of crash data.




General Motors AIR BAG SDM / BLACK BOX / EDR / CRASH DATA AVAILABLE FOR DOWNLOAD:

(Depending on model year and SDM module configuration)


Vehicle speed (in five one-second intervals preceding impact)
Engine speed (in five one-second intervals preceding impact)
Brake status (in five one-second intervals preceding impact)
Throttle position (in five one-second intervals preceding impact)
Driver's seat belt state (On/Off)
Passenger's airbag enabled or disabled state (On/Off)
Airbag Warning Lamp status (On/Off)
Time from vehicle impact to airbag deployment
Maximum Delta-V ( DV ) for near-deployment event
Delta-V ( DV ) vs. time for frontal airbag deployment event
Time from vehicle impact to time of maximum Delta-V ( DV )
Time between near-deploy and deploy event (if within 5 seconds)


ADDITIONAL CRASH DATA AVAILABLE FOR DOWNLOAD 2006 AND NEWER GM VEHICLES:

  Low tire pressure warning system status
  Traction control status
  Anti lock brake status
  Transmission range
  Service engine lamp status
  Vehicle door 2/4 status open/closed
  Outside air temperature degrees F
  Passenger seat belt switch
  Yaw rate
  Lateral acceleration
  Steering wheel angle
  PDOF / Principal direction of force degrees
  And more...



GM air bag SDM 5 seconds of pre-crash (AE) vehicle data.

GM air bag SDM velocity speed change in milliseconds after AE.

Air bag system status at deployment / non deployment.

GM air bag SDM hexadecimal data.


Picture shows GM SDM air bag module, printed crash data, CD-ROM crash data. ©


What information is available from OnStar?


OnStar can provide date and time of crash notification, basic GPS
 location, maximum recorded Delta V, and direction of impact.

You must have a active OnStar account at the time of the accident.

You do have to make a request for the OnStar service records. ©







 Why was I not told my GM car had a 'black box' when I bought it?


Ask a GM service department if your GM car has a black box, chances are you'll get a funny look in return. Most GM dealers are unaware of the recording ability of the air bag SDM. They may claim there is no black box on the vehicle. Or they may claim the GM Tech 2 can access everything in the vehicle. Both statements are simply not true.


The fact that the air bag module is recording data is explained in the vehicles owners manual.


Example: 2001 Cadillac owners manual statement:


"Your vehicle is equipped with an electronic frontal sensor, which helps the sensing system distinguish between a moderate frontal impact and a more severe frontal impact. Your vehicle is also equipped with a crash sensing and diagnostic module, which records information about the frontal air bag system. The module records information about the readiness of the system, when the system commands air bag inflation and driver's safety belt useage at deployment or near-deployment crash. The module also records speed, engine rpm, brake and throttle data."




• Who owns the air bag SDM /EDR 'black box' module crash data?


Basically, the owner of the vehicle owns the crash data. Example: If a insurance company pays off your wrecked vehicle, they now own the air bag SDM crash data. Then, if the insurance company sells the vehicle to a salvage yard, then the salvage yard now owns the air bag crash data.




LINK: Cnetnews.com black box article using www.airbagcrash.com images


Link: USA Today article using airbagcrash images






2006 NHTSA, NTSB 'mandate' recommendation of standardizing EDR (event data recorder) crash data for model year 2011 motor vehicles.

Delta V, longitudinal
Time, maximum delta V
Speed, vehicle indicated
Engine throttle, % full (or accelerator pedal, %full)
Service brake, on/off
Ignition cycle @ crash
Ignition cycle @ download
Safety belt status, driver
Frontal air bag warning lamp
Frontal air bag deployment, time to deploy, first stage, dual stage, drivers
Frontal air bag deployment, time to deploy, first stage, dual stage, passenger
Multi-event, number of events (1-2)
Time from event 1 to 2
Complete file recorded (yes/no)
Lateral acceleration
Longitudinal acceleration
Normal acceleration
Delta V, lateral
Maximum delta V, lateral
Time maximum delta V, lateral
Time for maximum delta V, resultant
Engine RPM
Vehicle roll angle
ABS activity (engaged, non-engaged)
Stability control (on, off, engaged)
Steering input
Safety belt status front passenger
Frontal air bag suppression switch status (on, off, or auto)
Frontal air bag deployment, time to n'th stage, driver
Frontal air bag deployment, time to n'th stage, passenger
Frontal air bag deployment, n'th stage disposal, driver Y/N
Frontal air bag deployment, n'th stage disposal, right front passenger Y/N
Side air bag deployment, time to deploy, driver
Side air bag deployment, time to deploy, right front passenger
Side curtain/tube air bag deployment, time to deploy, driver side
Side curtain/tube air bag deployment, time to deploy, right side
Pretensioner deployment, time to fire, driver
Pretensioner deployment, time to fire, passenger
Seat track position switch, foremost, status, driver
Seat track position switch, foremost, status, passenger
Occupant size classification, driver
Occupant size classification, passenger
Occupant position driver
Occupant position passenger
